AquaT3500™ Human Alkaline Hydrolysis System

Simple, elegant, and reliable. Our patented rotational alkaline hydrolysis technology sets a new benchmark for quick, efficient 4 hour processing of decedents in a non-pressurized system. Our small footprint, hydrolytic system comes complete with standard options other manufactures charge extra for. Chemical injection, filtration , discharge pumps and integrated Ethernet for operator remote monitoring and offsite technical troubleshooting – all come standard with the AquaT3500™. Plus a whole new set of unique features that make the AquaT3500™ the most cost effective alkaline hydrolysis system on the market today!

Interactive 3D Model

Key Benefits

  • Short 4 hour cycles, start to finish. A fourfold improvement on efficiency
  • Small footprint, with no noise or odors for hassle-free positioning
  • Heat recapture during cooling saves on energy costs and water usage
  • Efficient pH adjustment within the main system or discharge to our treatment tank for further refinement to meet or exceed municipal regulations
  • Safe, reliable, low maintenance system, Made in USA

Advanced Features

  • Removable inner cradle for easy loading and collection of remains
  • Gentle “swish” rocking motion promoting a respectful , caring disposition
  • Unique internal proprietary baffles help facilitate short 4 hour cycle times
  • Fully customizable cycle recipes to suit the decedent’s characteristics
  • Built-in energy recovery system to recapture heat energy for the next cycle
  • Counterweight lid allows for effortless, single person access.

Download Brochure

Download our products brochure

How It Works

  1. 1

    Respectful handling of the decedent

    The inner perforated cradle can be hoisted out of the hydrolytic chamber allowing for the decedent to be carefully loaded into the cradle bottom from a work platform or gurney. The cradle lid is attached and the secure body and cradle are hoisted and lowered back into the chamber. The body can be weighed prior or during hoisting with a load cell configured to the operator’s choice of hoist.

  2. 2

    Short 4-hour process cycle

    After securing the cradle spindles within the chamber the lid is closed and secured. A volume of water and liquid potassium hydroxide is added based on body weight . Internal immersion heaters bring the temperature up to 200F and the process starts with a gentle “swish” rocking pattern.

  3. 3

    Cooling and pH adjustment

    When the cycle is complete the liquid bi-product is cooled with our proprietary heat recovery system and the resulting warm water is stored for the next cycle. pH is adjusted with acid injection and the liquid bi-product is then discharged from the main chamber , passing through a filtration system to capture fine bone remains.

  4. 4

    Clean, rinse and removal

    The system proceeds through the soap wash/rinse cycle ensuring the bone remains and the equipment are clean. The cradle can be lifted free of the chamber to allow for easy recovery of the solid bone remains from the bottom portion of the cradle. Operators also have the option to simply remove the top to the cradle to access the bones remains while still in the system.
